Optimization methods

In this lecture, we discuss the optimization methods used to correct weights in neural networks. There are several classes of optimization methods, but the most common ones use to be based on gradient descent. The most popular methods, i.e., Adam, RMSProp, and SGD with momentum, are all based on calculating the gradient of the loss function with respect to the weights and then updating the weights in the opposite direction of the gradient. However, thera are also other methods, which use the second order derivatives of the loss function, such as Newton’s method and quasi-Newton methods. These methods can converge faster than gradient descent, but they are also more computationally expensive, cause they require calculating the Hessian matrix. In practice, these methods are not commonly used for training neural networks, because they can be very slow and require a lot of memory. Instead, most practitioners use gradient-based optimization methods, which are more efficient and can still achieve good results.

Problem formulation

The unconstrained optimization problem can be formulated as follows: let’s regard the loss function as a function of the weights, i.e., $\boldsymbol{E}(w)$ , where $w$ is the vector of weights. The goal is to find the weights $\boldsymbol{w^*}$ that minimize the loss function, i.e.,

\boldsymbol{w^*} = \arg\min_{\boldsymbol{w}} \boldsymbol{E}(\boldsymbol{w}).

For minimum of the loss function it is necessary to satisfy the following conditions:

\frac{\partial \boldsymbol{E}}{\partial \boldsymbol{w^*}} = 0 = \nabla \boldsymbol{E}(\boldsymbol{w^*}), \quad \text{and} \quad \frac{\partial^2 \boldsymbol{E}}{\partial \boldsymbol{w^*}^2} > 0.

where

\nabla = \left( \frac{\partial}{\partial w_1}, \frac{\partial}{\partial w_2}, \ldots, \frac{\partial}{\partial w_n} \right)^T

and

\nabla \boldsymbol{E}(\boldsymbol{w}) = \left( \frac{\partial \boldsymbol{E}}{\partial w_1}, \frac{\partial \boldsymbol{E}}{\partial w_2}, \ldots, \frac{\partial \boldsymbol{E}}{\partial w_n} \right)^T

The most common optimization methods are based on iterative descent, which means that we start with an initial guess for the weights and then iteratively update the weights in the opposite direction of the gradient until we reach a local minimum. We suppose that for every next iteration the loss function will decrease, i.e., $\boldsymbol{E}(\boldsymbol{w}_{n+1}) < \boldsymbol{E}(\boldsymbol{w}_n)$ .

Gradient descent

The most basic optimization method is gradient descent, which updates the weights as follows:

\boldsymbol{w}_{n+1} = \boldsymbol{w}_n - \eta \boldsymbol{g}_n,

where $\eta$ is the learning rate and $\boldsymbol{g}_n = \nabla \boldsymbol{E}(\boldsymbol{w}_n)$ is the gradient of the loss function with respect to the weights at iteration $n$ . The learning rate controls how much we update the weights in each iteration. If the learning rate is too small, the optimization process will be slow and may get stuck in a local minimum. If the learning rate is too large, the optimization process may diverge and fail to find a minimum.

Let’s show that for next iteration the loss function will decrease, i.e., $\boldsymbol{E}(\boldsymbol{w}_{n+1}) < \boldsymbol{E}(\boldsymbol{w}_n)$ . We can use the Taylor expansion of the loss function around $\boldsymbol{w}_n$ :

\boldsymbol{E}(\boldsymbol{w}_{n+1}) = \boldsymbol{E}(\boldsymbol{w}_n) - \eta \boldsymbol{g}_n^T \boldsymbol{g}_n = \boldsymbol{E}(\boldsymbol{w}_n) - \eta \|\boldsymbol{g}_n\|^2 < \boldsymbol{E}(\boldsymbol{w}_n)

Consequently, the loss function will decrease in each iteration as long as the learning rate is positive and small and the gradient is not zero. However, gradient descent can be slow to converge, especially for large and complex neural networks. Therefore, several variants of gradient descent have been developed to improve convergence speed and stability.

Adam - Adaptive Moment Estimation

Adam is a stochastic optimization method that includes the combination of exponential moving average of gradients(first moment) and the exponential moving average of squared gradients (second moment).

The classic Adam method includes several parameters:

$\alpha$ - learning rate,
$\beta_1$ - exponential decay rate for the first moment estimates(usually set to 0.9),
$\beta_2$ - exponential decay rate for the second moment estimates(usually set to 0.999),
$\varepsilon$ - a small constant for numerical stability(usually set to 1e-8).

Let’s consider the transitiom from iteration $n$ to iteration $n+1$ . Firstly, we compute the gradient of the loss function with respect to the weights, i.e.,

\boldsymbol{g}_n = \nabla \boldsymbol{E}(\boldsymbol{w}_n)

Secondly, we update the biased first moment estimate and the biased second moment estimate as follows:

\boldsymbol{m}_n = \beta_1 \boldsymbol{m}_{n-1} + (1 - \beta_1) \boldsymbol{g}_n

\boldsymbol{v}_n = \beta_2 \boldsymbol{v}_{n-1} + (1 - \beta_2) \boldsymbol{g}_n^2

Thirddly, we compute the bias-corrected first moment estimate and the bias-corrected second moment estimate as follows:

\hat{\boldsymbol{m}}_n = \frac{\boldsymbol{m}_n}{1 - \beta_1^n}

\hat{\boldsymbol{v}}_n = \frac{\boldsymbol{v}_n}{1 - \beta_2^n}

Finally, we update the weights as follows:

\boldsymbol{w}_{n+1} = \boldsymbol{w}_n - \alpha \frac{\hat{\boldsymbol{m}}_n}{\sqrt{\hat{\boldsymbol{v}}_n} + \varepsilon}

The advantage of Adam is that it can adapt the learning rate for each weight based on the historical gradients, which can lead to faster convergence and better performance. However, Adam can also be sensitive to the choice of hyperparameters and may not always converge to the optimal solution. Therefore, it is important to carefully tune the hyperparameters when using Adam for training neural networks.

Stochastic Gradient Descent

The other popular optimization method is stochastic gradient descent (SGD), which updates the weights using a randomly selected subset of the training data, called a mini-batch. The update rule for SGD is similar to that of gradient descent, but it uses the average gradient computed over the mini-batch instead of the full dataset.

Let’s consider the transition from iteration $n$ to iteration $n+1$ for SGD. Firstly, we randomly select a mini-batch of training data and compute the average gradient of the loss function with respect to the weights over the mini-batch, i.e.,

\boldsymbol{g}_n = \frac{1}{m} \sum_{i=1}^m \nabla \boldsymbol{E}(\boldsymbol{w}_n; x_i, y_i)

where $m$ is the size of the mini-batch and $(x_i, y_i)$ are the training examples in the mini-batch.

Secondly, we update the weights as follows:

\boldsymbol{w}_{n+1} = \boldsymbol{w}_n - \alpha \boldsymbol{g}_n

Thirdly, it’s necessary to go to the next mini-batch and repeat the process until we have gone through the entire dataset. This process is called an epoch. The advantage of SGD is that it can be more efficient for training large neural networks with a lot of data, but it can also be more sensitive to the choice of hyperparameters and may require more careful tuning to achieve good performance.
